In certain scenarios, there might be a need for having multiple screens to be shared at the same time. With Vonage Video API, you have an opportunity to do exactly that.
This blog post will show how to build a simple Javascript application that utilizes Vonage Video API that allows having multiple screen share streams at the same time. This can be useful for collaboration efforts or for simple fun, such as playing a game of tic-tac-toe together with friends or family.
To develop this project, you are going to need the following:
Vonage Video API account
Basic knowledge of JavaScript
Video API documentation
Clone certain GitHub repositories
We will use a Basic Video Chat sample from the Opentok Github directory as a starting point for this tutorial. Please download the following repository - https://github.com/opentok/opentok-web-samples and we will be working with the Basic Video Chat part of this repository.
We will be using a session ID and token generated through your Vonage Video API account. Please visit tokbox.com/account to do so and copy-paste information to the config.js file of the repository. For a deployed application, it is recommended that you generate session IDs and tokens via the backend server.
In the Basic Video Chat sample app, navigate to the index.html, and let’s add a button for the screen share.
Add the following code in the <body> of the HTML page:
<button onclick="”screenShare()”">Share your screen </button>Now navigate to the js/app.js part of the codebase and add the following screenShare() function:
function screenShare() {
OT.checkScreenSharingCapability(function(response) {
if(!response.supported || response.extensionRegistered === false) {
console.log("screen sharing is not supported")
} else if (response.extensionInstalled === false) {
console.log("older browser like IE might require a plugin")
} else {
// Screen sharing is available. Publish the screen.
var publisher = OT.initPublisher('screenshare',
{videoSource: 'screen'},
function(error) {
if (error) {
console.log(error);
} else {
session.publish(publisher, function(error) {
if (error) {
console.log(error);
}
});
}
}
);
}
});
}After this, go back to the index.html file and add the <div> for the screensharing stream:
<div>
<div id="”subscriber”"></div>
<div id="”publisher”"></div>
<div id="”sceenshare”"></div>
</div>We would like to keep publisher, subscriber, and screen-share streams separate to make sure that users can also see each other during the screen sharing activity. You can update the css/app.css file to add additional layout styling; however, without any changes, the screen-sharing streams will appear in the upper left corner.
To test this, open the index.html file in your browser (such as Google Chrome), publish your video and click the “Share your screen” button underneath your video stream. Afterward, join from a different device or browser to test this out!
In conclusion, this article showed you a simple way to enhance the Basic Video Chat app with screen-sharing capabilities that allow users to share their screens simultaneously. This was done through enhancements to the HTML and JavaScript files of the existing OpenTok GitHub repository.
