In this post, we are going to look at streaming an audio file into an in-progress phone call. There are many use cases for streaming audio files into calls, and with the Vonage Voice API and the Vonage Ruby gem, it is a relatively straightforward process. Whether you want to share music with someone over the phone or a snippet from a work meeting, you can do so with a few lines of Ruby and Vonage.

The source code for this blog post is available on GitHub.

Prerequisites

To work through this post, you'll need:

Vonage API Account

To complete this tutorial, you will need a Vonage API account. If you don’t have one already, you can sign up today and start building with free credit. Once you have an account, you can find your API Key and API Secret at the top of the Vonage API Dashboard.

This tutorial also uses a virtual phone number. To purchase one, go to Numbers > Buy Numbers and search for one that meets your needs.

Ready to start building?

Experience seamless connectivity, real-time messaging, and crystal-clear voice and video calls—all at your fingertips.

• Ruby 2.5.3 or newer

• The dotenv gem

• Sinatra

• Vonage CLI

Configure your Vonage Account and Application

Let's start by purchasing a phone number we can use for testing. We'll use the Vonage CLI to purchase the number.

Here, NUMBER represents the number that you want to purchase, and COUNTRYCODE the country code for that number.

If you don't already know the number you want to buy, you can first search for a number in a particular country like so (here we're searching for numbers in the USA using the US country code):

Go ahead and make a note of the phone number you just purchased. We will be using it in just a moment in our code.

We'll also use the Vonage CLI to create a new application. We need to create an application to use the Voice API.

Executing that command, we have now created a new application called "Test Application 1" and defined three parameters:

• answer_url: Where our application delivers the Vonage Call Control Object (NCCO) that governs the call

• event_url: Where Vonage sends the event information asynchronously when the call_status changes

We will redefine both the answer_url and the event_url in our code. It is important to note that they need to be externally accessible URLs for the Vonage platform to access. For our local installation, we can use ngrok to make our local server externally available. You can find more information on using Vonage with ngrok at this blog post.

Running the vonage apps:create command also outputs an application ID for the created application. We will use this id in a moment in our code, alongside the new phone number we acquired.

Setting up Our Credentials

At this point, we now have the information we need to create our application. We are going to create a Sinatra web server that serves four routes, three GET requests and a POST request. The GET requests initiate the phone call, provide the NCCO instructions to the Vonage platform and streams a silent file to keep the call open. The POST request streams the audio to the call once it has been answered.

To access our Vonage account and to authenticate ourselves we need to provide the correct credentials. You should take care to store these securely and avoid checkling them into source control. In this example, we are going to use the dotenv gem to store our credentials as environment variables and access them in our code accordingly. We do that by first creating a file called .env and putting the following inside:

VONAGE_API_KEY=
VONAGE_API_SECRET=
VONAGE_APPLICATION_ID=
VONAGE_APPLICATION_PRIVATE_KEY_PATH=private.key
VONAGE_TO_NUMBER=
VONAGE_NUMBER=

Your VONAGE_API_KEY and VONAGE_API_SECRET were provided to you when you signed up for a Vonage account at the beginning of this walkthrough. You can reaccess them in your account settings. Your VONAGE_APPLICATION_ID is what was returned to you when you created a new application with the Nexmo CLI. Likewise, your VONAGE_APPLICATION_PRIVATE_KEY_PATH is the file path to the private.key file automatically created when initializing a new application with the CLI. In our example, it is ./private.key. Your VONAGE_NUMBER is the phone number you purchased, and the VONAGE_TO_NUMBER is the phone number you wish to call.

If you are committing this to GitHub, please make sure also to create a .gitignore file and adding .env inside of it to ensure that your credentials do not get published online by accident.

Sending Streaming Audio to a Call with Ruby

Let's create a new file called server.rb and make sure we are requiring our necessary dependencies and loading our dotenv environment variables:

require 'sinatra'
require 'vonage'
require 'dotenv'
require 'json'

Dotenv.load

Next, we are going to initialize a new Vonage client instance utilizing those credentials and the Vonage gem.

client = Vonage::Client.new(
  api_key: ENV['VONAGE_API_KEY'],
  api_secret: ENV['VONAGE_API_SECRET'],
  application_id: ENV['VONAGE_APPLICATION_ID'],
  private_key: File.read(ENV['VONAGE_APPLICATION_PRIVATE_KEY_PATH'])
)

At this point, we now have a credentialed Vonage client instance and our streaming audio defined. What are we missing? The phone call of course!

First, let's get our ngrok externally accessible URL that we will use to make our server available to Vonage to receive our call instructions from and to send call status updates back to. Once you have installed ngrok, open a new console window and execute ngrok http 4567 from the command line. This will initiate a new ngrok server on port 4567 that parallels our Sinatra server, which is also running on port 4567. You will see a status displayed to you that contains the ngrok URL under the Forwarding parameter. Go ahead and copy and paste that URL into the BASE_URL constant variable in server.rb.

BASE_URL = 'PASTE URL HERE'

While we are defining our variables, let's go ahead and set the path to our streaming audio file, and we'll define it as a CONSTANT variable.

AUDIO_URL = "#{BASE_URL}/voice_api_audio_streaming.mp3"

We now can create a URL path to /new that when accessed will start the phone call.

get '/new' do
  response = client.calls.create(
    to: [{ type: 'phone', number: ENV['VONAGE_NUMBER'] }],
    from: { type: 'phone', number: ENV['VONAGE_TO_NUMBER'] },
    answer_url: ["#{BASE_URL}/answer"],
    event_url: ["#{BASE_URL}/event"]
  )
  puts response.inspect
end

The get /new action above creates a new phone call with the to:, from:, answer_url: and event_url: parameters provided.

The to: and from: parameters require both a type and a number. In our case, the type for both is phone. The answer_url and event_url need to be externally accessible URLs that the Vonage platform can receive instructions from and send call status updates to, respectively.

Once we initiate the phone call, Vonage accesses the answer_url path looking for call instructions. We need to create that action as well. The action will render and deliver the instructions as JSON. The instructions provide the action, the URL path to a silent audio file that will play in the background keeping the connection open and a loop parameter, which we set to 0.

get '/answer' do
    # Provide the Vonage Call Control Object (NCCO) as JSON to the Vonage Platform
    content_type :json
    [{ :action => 'stream', :streamUrl => ["#{BASE_URL}/stream/silent"], :loop => 0 }].to_json
end

At this point, we need to create one more GET path to deliver the silent audio file that we specified in the NCCO instructions:

get '/stream/silent' do
    # Stream a silent file in the background to keep the call open
    send_file File.join(settings.public_folder, 'silence.mp3')
end

Lastly, we also create a POST path to /event that receives the call status from the Vonage platform and send the streaming audio once it has been answered. The action parses the data received and uses the status parameter to determine when the call has been answered. A call's status changes from started to ringing and then answered and finally, when it is disconnected, to completed. Our code plays the audio file once the status has reached answered. We also receive the unique identifier for this call, the uuid, from the data received, which is required for us to inject our streaming audio into this specific call.

post '/event' do
  data = JSON.parse(request.body.read)
  response = client.calls.stream.start(data['uuid'], stream_url: [AUDIO_URL]) if data['status'] == 'answered'
  puts response.inspect
end

So with that POST action, we have finished creating our application. Now, we just need to run ruby server.rb from the command line to boot up our server and make sure we initialized ngrok to make our local server externally accessible. Once that is done, go ahead and navigate to http://localhost:4567 from your web browser and you will receive the phone call. When you answer the call, the audio will begin streaming.

Conclusion

In approximately 40 lines of code, we have created a fully functioning web server that can call any phone number and play streaming audio into that call. There is a lot more that can be done with the Vonage Voice API and you can explore it entirely on the Vonage Developer Platform.

If you have any questions about this post feel free to email devrel@nexmo.com or join the Vonage community Slack channel, where we're waiting and ready to help.
