It's nearly Christmas and another year has almost gone!
I thought I would see out the year with a fun and easy piece of Python code to allow you to dial a Christmas carol to put a smile on your face - or make you cringe...
Here's the main idea:
You dial a Nexmo Number
You hear a selection menu
You make your choice
You hear a cringeworthy carol!
Awesome!
To complete this tutorial, you will need a Vonage API account. If you don’t have one already, you can sign up today and start building with free credit. Once you have an account, you can find your API Key and API Secret at the top of the Vonage API Dashboard.
This tutorial also uses a virtual phone number. To purchase one, go to Numbers > Buy Numbers and search for one that meets your needs.
If you've not played with Nexmo to date I recommend our documentation as a first port of call.
I am also going to assume you know how to configure your webhooks. Also you can host your webhook server on a platform of your choice, or you can test locally using Ngrok. If you've not used Ngrok before I recommend you take a look at our Ngrok tutorial blog post and also read our documentation on it.
So, you are now ready to make sure you configure your webhooks. I will assume you are testing locally with Ngrok and you have them set along the following lines:
Webhook | URL
---- | ----
answer | https://abcdef1.ngrok.io:3000/webhooks/answer
event | https://abcdef1.ngrok.io:3000/webhooks/event
NOTE: This assumes your webhook server is running on port 3000, but it can be any suitable port.
There is one other webhook of interest in this tutorial, but you don't set it in the same way you set the Answer webhook or Event webhook URLs. It's the DTMF webhook that you will see in the next section.
When you dial into your Nexmo Number, you will hear an option menu. You can then select your carol by pressing a key on your phone keypad. This input is sent to your application via a POST on the DTMF webhook, which has the form https://abcdef1.ngrok.io:3000/webhooks/dtmf.
So how does Nexmo know how to call back on this URL? You have to set the DTMF webhook in your Answer webhook code.
Looking at the Answer webhook you see the following:
@app.route("/webhooks/answer")
def answer_call():
params = request.args
input_webhook_url = request.url_root + "webhooks/dtmf"
ncco = [
{
"action": "talk",
"bargeIn": "true",
"text": menu
},
{
"action": "input",
"maxDigits": 1,
"timeOut": 5,
"eventUrl": [input_webhook_url]
}
]
return jsonify(ncco)Looking at this code you can see that when your inbound call is answered, the NCCO that controls the call sends you the option menu via Nexmo's Text-To-Speech capabilities, and also sets the DTMF webhook. This is how Nexmo knows where to call back on with input from the phone keypad.
There's also a couple of parameters specified. The timeOut parameter in this case is set to slightly longer than the default of three seconds. In this case it gives you a five second period in which to respond with a key press before the system times out on waiting for input. maxDigits in this will make sure only one digit is accepted as input.
The other parameter worth mentioning is bargeIn which is set to true in this case. This allows you to interrupt the option menu for those instances when you simply can't wait to hear your favourite carol!
There is also more detailed documentation on DTMF you can read at your leisure. I just covered the basics here.
You just saw how the Answer webhook works. Now you'll see how the DTMF webhook works.
First here's the code:
@app.route("/webhooks/dtmf", methods=['POST'])
def dtmf_webhook():
data = request.get_json()
selection = data['dtmf']
if selection == "":
selection = "1"
index = int(selection)-1
if index < 0 or index > len(tunes)-1:
index = 0
carol_url = base_url + tunes[index][1]
print(tunes[index][1])
msg = "Playing Christmas carol " + str(index+1)
ncco = [
{
"action": "talk",
"text": msg
},
{
"action": "stream",
"streamUrl": [carol_url]
}
]
return jsonify(ncco)You can see we are only interested in a POST callback on this URL. Mostly this code is to make sure we handle the case where the user doesn't enter an option at all, or selects an option that's outside of the range presented in the option menu. The real action happens again in the NCCO.
In the NCCO there is a little prompt message which announces which carol is going to be played. Then the stream action is used to play an MP3 file into the call. This feature is quite useful for things like on-hold music and so on, but we can use it in this case to get our festive fix. You only need to specify the URL and the music is, by amazing Nexmo magic, played into your call.
I've covered the most important parts of the code. Here's the complete code for your convenience:
#!/usr/bin/env python3
from flask import Flask, request, jsonify
from pprint import pprint
app = Flask(__name__)
base_url = 'https://raw.githubusercontent.com/tbedford/git-testing-repo/master/tunes/xmas/'
# Tunes courtesy http://www.freexmasmp3.com/
tunes = [
["Little Town of Bethlehem", "bethlem-jazz.mp3"],
["Ding Dong Merrily", "ding-dong-merrily.mp3"],
["First Noel", "first-noel-r-and-b.mp3"],
["Jingle Bells", "jingle-bells-country.mp3"],
["Silent Night", "silent-night-piano.mp3"],
["Twelve Days of Christmas", "twelve-days-funk.mp3"]
]
# Build options menu
menu = "Welcome to dial a Christmas carol. You can choose from the following cheesy carols."
i = 1
for t in tunes:
menu = menu + " Option " + str(i) + " is " + t[0] +"."
i = i + 1
menu = menu + " Please make your selection now."
@app.route("/webhooks/answer")
def answer_call():
params = request.args
input_webhook_url = request.url_root + "webhooks/dtmf"
ncco = [
{
"action": "talk",
"bargeIn": "true",
"text": menu
},
{
"action": "input",
"maxDigits": 1,
"timeOut": 5,
"eventUrl": [input_webhook_url]
}
]
return jsonify(ncco)
@app.route("/webhooks/dtmf", methods=['POST'])
def dtmf_webhook():
data = request.get_json()
selection = data['dtmf']
if selection == "":
selection = "1"
index = int(selection)-1
if index < 0 or index > len(tunes)-1:
index = 0
carol_url = base_url + tunes[index][1]
print(tunes[index][1])
msg = "Playing Christmas carol " + str(index+1)
ncco = [
{
"action": "talk",
"text": msg
},
{
"action": "stream",
"streamUrl": [carol_url]
}
]
return jsonify(ncco)
@app.route("/webhooks/event", methods=['POST'])
def events():
data = request.get_json()
pprint(data)
return ("OK")
if __name__ == '__main__':
app.run(port=3000)Once you have your application running, just dial into Nexmo using your Nexmo Number, make your selection from the options provided via your phone keypad, and listen to some festive fun.
So, I hope you have enjoyed this Christmas code.
I would like to take this opportunity to wish you all a very Merry Christmas and a Happy New Year!
The source code is available on GitHub:
Here are some resources that will be useful if you want to explore things further:
NCCO Reference - this describes the
inputaction in detail.Ngrok tutorial - a useful guide to testing your app locally.
Webhooks - everything you ever wanted to know about Webhooks but were afraid to ask.
